| We offers a wide range of reduction gearboxes for actuator and screw jack system building whether it be a single motorised actuator or several screw jacks mechanically linked. The gearboxes available are available as motorised units as standard, however the gearbox unit itself can be supplied. The most popular types of gearboxes are Helical Worm Gearboxes, In-line Helical and Parallel Shaft, other types are available on request. | |||||||||
0.12 kW - 18.5 kW
JACTON
Product Description
RV Worm Gearbox And Gear Motors are important components in Motorised Screw Jack Systems and it is important to select the best option based on torque requirements. Worm Gear Reducers are available with standard IEC motor flange or NEMA C-Face mounting flanges. Their aluminum alloy housings with heat sink properties provide maximum cooling efficiencies. Screw jacks and lifting systems offer wide-ranging lifting and positioning solutions for diverse industries. Our robust jacks reliably move and accurately position loads up to 100-tons. We configures jacks with components such as motors, gear reducers, shafting, coupling, and motion control devices to create complete multi-jack systems. NMRV worm gear reducers currently represent the most advanced solution to market requirements in terms of efficiency and flexibility. The new NMRV Power series, also available as compact integral helical/worm option, has been designed with a view to modularity: low number of basic models can be applied to a wide range of power ratings guaranteeing top performance and reduction ratios from 5 to 1000.
Features
* NMRV Sizes: 025-030-040-050-063-075-090-110-130-150
* Available versions: fitted for motor coupling, with input shaft, with torque limiter
* Power up to 18,5 kW
* Cases up to 110 in die-cast aluminium alloy and over 130 in G200 grey cast iron
* Ratios between 5 and 100
* Max torque 1.550 Nm and admissible radial loads max 18.000 N
* Aluminium units are supplied complete with synthetic oil and allow for universal mounting positions, with no need to modify lubricant quantity
* Worm wheel: bronze
* Worm gear reducers are available with diffferent combinations: NMRV+NMRV, NRV+NMRV.
* Options: protection cover, torque arm, output flange, output shaft kit, torque limiter, viton oil seals, low/high temperature and food grade oil, filling/drain/breather/level plug, reinforced output.
Download
Speficications | Dimensional Drawings | Catalog
Application Case
We offers all of the components necessary to complete your power transmission system, whether it consists of a single screw jack actuator or a multiple screw jack actuator arrangement. We offer a complete line of accessories to interconnect two or more screw jack actuators and provide permanent synchronization. We's Application Engineers can specify shafts, couplings, pillow blocks, and right-angle miter gearboxes to accommodate any layout. Bellows boots to protect screw jack actuator screws from dirt and other contaminates are available for all screw jack actuators, to increase life and reduce maintenance requirements. Our extensive experience in actuator systems can provide you with suggestions for the most economical and reliable method to complete your lifting system.
