| Custom Lifting Solutions: Let us customize our products so you don't have to customize yours. Sometimes the screw jack actuator needs a special modification to meet your application requirements. Typical modifications of the screw jacks include special stroke length, travel speed, motor power, gear ratio, motor mounts, screw end fittings, materials, bellows boots and other modifications are possible. The worm gear screw jacks design is fully customisable by our engineering team to meet your exact application requirements. Thanks to our experts, all our customized worm gear screw jacks are of high usage among our clients to support their project running smoothly. We specialize in skillful customizations and we are confident that we can help you find a solution for your toughest challenges. Talk with an Application Engineer about your requirements today. | |||||||||
JTN-1T
JACTON
The dimensions of 1-ton Miniature Worm Gear Machine Screw Jacks are same as US markets screw jacks. Screw diameter 20mm, pitch 5mm. Gear ratio: 5:1, 20:1. Upright or Inverted configurations. Screw end conditions: I: top plate, II: clevis end, III: plain end, IV: threaded end. Screw design: travelling screw, anti-rotation keyed screw, travelling nut rotating screw. Screw stroke is customized, you can design the travel following your requirements. Input shafts include single left input shaft, single right input shaft and double input shafts. Accessories include protective tube, bellow boots, motors, handwheels, couplings, connecting shafts, pillow blocks, flange blocks, linear bushings, limit switches etc.
1 Ton Machine Screw Jack offers a cost effective solution to a wide variety of industrial lifting, lowering, pushing and pulling applications. Contact us today, get a free solution now. In stock and ready to ship.
Product Material
We use the best materials to guarantee the performance and lifetime of the 1-ton Miniature Worm Gear Machine Screw Jacks you purchased.
* Housing: Die Casting Aluminum Alloy.
* Lifting Screw: C45 Steel as Standard. Custom Stainless Steel 304 or 316.
* Input Shaft (Worm): C45 Steel in high frequency heat treatment process. Custom Stainless Steel 304 or 316.
* Worm Gear and Travel Nut: High strength bronze ZQAl9-4 (Casting aluminum bronze) as Standard. Custom High strength bronze ZCuSn10Pb1(Casting tin bronze).
* Bearing: Anti-friction Ball Thrust Bearings as standard. Custom stainless steel #304.
* Protective Tube: Aluminum Alloy. Custom Stainless Steel 304.
* Lubricants: Synthetic Grease, Extreme Pressure EP2 Lithium Grease.
Download
Speficications | Dimensional Drawings | Selection Guide | Catalog
Packaging and Shipping
* 100% standard exporting plywood cases (international exporting standard wooden material with free fumigation).
* Express(Air): Factory to customers' company by FEDEX, DHL, UPS, TNT. Incoterms: EXW, DDU.
* Sea Freight: Factory to destination seaport by Vessel. Incoterms: CIF, FOB, EXW, CFR.
* Air Freight: Factory to destination airport by Airplane. Incoterms: CFR, EXW, FCA, CPT, CIP.
* Additional Options (Door to Door): Train Transportation, Truck Transportation, Ocean Shipping
