| F87 FF87 Helical Parallel Gearmotors FA87 FAF87 Gear Reducers with motor power 5.5kw, 7.5kw, 11kw, 15kw, 18.5kw and 22kw, max. permissible torque up to 3000Nm, transmission ratios from 4.12 to 270.68. Transmission stage: 2 stage or 3 stage. Transmission efficiency: 2-stage 96%; 3-stage 94%. Mounting option: foot mounted, flange mounted, short flange mounted, torque arm mounted. Output shaft: solid shaft, hollow shaft (with key, with shrink disc and with involute spline). F87: Foot-mounted, solid shaft output. FA87: Keyed hollow shaft output. FAB87: Foot-mounted, hollow shaft output. FF87: B5 Flange-mounted, solid shaft output. FAF87: B5 Flange-mounted, hollow shaft output. FAZ87: B14 Flange-mounted, hollow shaft output. FAT87: Torque-arm mounted, hollow shaft output. FH87, FHB87, FHF87, FHZ87: Hollow shaft output and shrink disk. FV87, FVB87, FVF87, FVZ87: Hollow shaft output and splined hollow shaft. | |||||||||
F87, FA87, FF87, FAF87, FAB87, FAT87, FAZ87
JACTON
Product Description
F87 FF87 Helical Parallel Gearmotors FA87 FAF87 Gear Reducers with motor power 5.5kw, 7.5kw, 11kw, 15kw, 18.5kw and 22kw, max. permissible torque up to 3000Nm, transmission ratios from 4.12 to 270.68. Transmission stage: 2 stage or 3 stage. Transmission efficiency: 2-stage 96%; 3-stage 94%. Mounting option: foot mounted, flange mounted, short flange mounted, torque arm mounted. Output shaft: solid shaft, hollow shaft (with key, with shrink disc and with involute spline). 2-stage or 3-stage helical gears. The gears are made of high quality alloy steel. The surface is hardened with the processes of carburizing and quenching, the teeth are made by fine grinding. So, as a whole, the gear is characterized with good tightness. Typically used in extruder, rotary cutter, cement mill, convery machine, conveyor and materials processing applications.
Parallel-shaft helical gearmotors with perfectly matched to limited installation space. The axis-parallel gear units have a slim design. We think they are always a good choice when space is limited. One of our best gear units for limited installation space. A wide range of mounting positions and variants enable a broad spectrum of applications even under difficult installation conditions – without having to compromise on the performance. And what applies to many of our gear units: long operating lives without maintenance and wear-free gearing with a high fatigue strength.
* F87: Foot-mounted, solid shaft output.
* FA87: Keyed hollow shaft output.
* FAB87: Foot-mounted, hollow shaft output.
* FF87: B5 Flange-mounted, solid shaft output.
* FAF87: B5 Flange-mounted, hollow shaft output.
* FAZ87: B14 Flange-mounted, hollow shaft output.
* FAT87: Torque-arm mounted, hollow shaft output.
* FH87, FHB87, FHF87, FHZ87: Hollow shaft output and shrink disk.
* FV87, FVB87, FVF87, FVZ87: Hollow shaft output and splined hollow shaft.
Main Features
1. Compact structure, modular design.
2. High efficiency of the gear units of over 95%.
3. Multi-stage(2 or 3 stages) gear units for low output speed.
4. Hollow output shaft with keyed connection, shrink disk, splined hollow shaft, or torque arm.
5. Can be combined with other types of gearboxes (Such as R Series, UDL Series).
6. Can be combined with various motors, for example: normal motor, brake motor, explosion-proof motor, frequency conversion motor, servomotor, stepper motor, IEC motor and other motors.
7. Space saving, reliable and durable, high capacity to withstand overload, wide range of rotation ratio, low energy consumption, superior performance, high efficiency, long life, low vibration, low noise, easy installation and beautiful appearance.
Product Components
We use the best materials to guarantee the performance and lifetime of the parallel shaft helical gearmotors you purchased.
* Housing: High strength cast iron
* Gears: Hardened Helical Gears
* Input Configurations
1. Equipped with Electric Motors
2. Solid Shaft Input
3. IEC Motor Flange
* Output Configurations
1. Solid Shaft Output
2. Hollow Shaft Output
* Applicable Motors
1. Three Phase AC Motors (normal)
2. Single Phase AC Motors (normal)
2. Brake Motors
3. Inverter Motors
4. Multi-speed Motors
5. Explosion-proof Motors
6. Roller Motors
7. Servo Motors
8. Stepper Motors
Download
Speficications | Dimensional Drawings | Selection Guide | Wiring Diagram For Limit Switches | Catalog
Application Case
Parallel shaft helical gearmotors are typically used in agriculture equipment, oil industry, belt conveyor, mixer, mixing machine, material handling, papermaking, sugar making, engineering machines, precision machine tools, military equipment, metallurgical equipment, daily necessities machinery, wind power equipment, chemical equipment, solar energy, industrial robots, transportation equipment, engineering machinery, textile equipment, rubber and plastic equipment, food machinery, sewage treatment, pharmacy, flat glass production lines, packaging equipment, printing equipment and automotive production lines.
Packaging and Shipping
* 100% standard exporting plywood cases (international exporting standard wooden material with free fumigation).
* Express(Air): Factory to customers' company by FEDEX, DHL, UPS, TNT. Incoterms: EXW, DDU.
* Sea Freight: Factory to destination seaport by Vessel. Incoterms: CIF, FOB, EXW, CFR.
* Air Freight: Factory to destination airport by Airplane. Incoterms: CFR, EXW, FCA, CPT, CIP.
* Additional Options (Door to Door): Train Transportation, Truck Transportation, Ocean Shipping.
