| R47 Inline Helical Speed Reducer RF47 Gearboxes and Gearmotors with motor power 0.18kw, 0.25kw, 0.37kw, 0.55kw, 0.75kw, 1.1kw, 1.5kw, 2.2kw, 3kw, 4kw and 5.5kw. Transmission gear reduction ratios 3.83 to 176.88. Available Versions include Single-stage or multi-stage, Foot-mounted or flange-mounted, Foot-mounted and flange-mounted, Flange-mounted with extended bearing hub. R47: Foot-mounted. RF47: B5 Flange-mounted. R47F: Foot and B5 Flange-mounted. RZ47: B14 Flange-mounted. | |||||||||
R47, RF47, R47F, RZ47
JACTON
Product Description
R47 Inline Helical Speed Reducer RF47 Gearboxes and Gearmotors with motor power 0.18kw, 0.25kw, 0.37kw, 0.55kw, 0.75kw, 1.1kw, 1.5kw, 2.2kw, 3kw, 4kw and 5.5kw. Transmission gear reduction ratios 3.83 to 176.88. The inline helical gearboxes and gearmotors combine high efficiency, flexible design, and a wide range of ratios with maximum reliability in a wide variety of applications and industries. The helical gear units offer an optimum ratio between torque output and installation space. The coaxial helical gearmotors are foot mounted, B5 flange mounted, B14 small flange mounted, with extended output bearing hub for agitator. helical gear units with solid output shaft, Input and output shafts are parallel to each other.
Applicable Motors include Y series IEC standard and IE2 high efficiency single and double speed motor, YVP, YVPEJ, YEJ, YDEJ series variable frequency and brake three-phase asynchronous motor, YZP, YZPEJ, YZRE series three-phase asynchronous motor for crane and metallurgical applications, YB, YBEJ, YBPT, YFB series explosion-proof three-phase asynchronous motor, YGa, YGb series table roller motor, Synchronous motor, DC motor, servo motor.
* R47: Foot-mounted.
* RF47: B5 Flange-mounted.
* R47F: Foot and B5 Flange-mounted.
* RZ47: B14 Flange-mounted.
Main Features
1. Small horizontal deviation of output shaft, compact structure, maximum utilization of housing space, accommodation of 2-stage and 3-stage gears in one case.
2. High efficiency, single-stage and two-stage 96%, three-stage 94%, and multi-stage combination of R/RF 85%.
3. Single-stage with high output speeds, multi-stage(2 or 3 stages) gear units for low output speed.
4. Unitary cast housing with high rigidity, enhanced shaft strength and extended bearing lifetime.
5. Can be combined with other types of gearboxes (Such as R Series, K Series, F Series, S Series, UDL Series).
6. Can be combined with various motors, for example: normal motor, brake motor, explosion-proof motor, frequency conversion motor, servomotor, stepper motor, IEC motor and other motors.
7. Coaxial gearbox, compact structure, small volume, reliable and durable, high load capacity, lightweight, high efficiency, wide range of rotation ratio, a wide range of motor power, low energy consumption, superior performance, high efficiency, long service life, low vibration, low noise and convenient mounting.
Product Components
We use the best materials to guarantee the performance and lifetime of the inline helical gear motors you purchased.
* Housing: High strength cast iron
* Gears: Helical Gears, 20CrMnTi
* Input Configurations
1. Equipped with Electric Motors
2. Solid Shaft Input
3. IEC or NEMA Motor Flange
* Output Configurations
1. Solid Shaft Output
* Applicable Motors
1. Three Phase AC Motors (normal)
2. Single Phase AC Motors (normal)
2. Brake Motors
3. Inverter Motors
4. Multi-speed Motors
5. Explosion-proof Motors
6. Roller Motors
7. Servo Motors
8. Stepper Motors
Download
Speficications | Dimensional Drawings | Selection Guide | Wiring Diagram For Limit Switches | Catalog
Application Case
Inline Helical Gear Motors are mainly used in metallurgical equipment, wind power equipment, chemical equipment, solar energy, industrial robots, transportation equipment, engineering machinery, textile equipment, rubber and plastic equipment, food machinery, sewage treatment, pharmacy, agriculture equipment, oil industry, belt conveyor, mixer, mixing machine, material handling, papermaking, sugar making, engineering machines, precision machine tools, military equipment, daily necessities machinery, flat glass production lines, packaging equipment, printing equipment and automotive production lines.
